Bently Nevada 3500/94 145988‑01 + 147663‑01 | Display Router + VGA Display Module Original

Overview
This combined set includes the 145988‑01 display router and 147663‑01 VGA display module for the 3500/94 system. The router directs rack video outputs to a display, while the VGA module presents system data and user interface. Brand: Bently Nevada. Country of Origin: USA.

General Information
Modules: 145988‑01 (Router) + 147663‑01 (VGA Display)
Manufacturer: Bently Nevada
Brand: Bently Nevada
Country of Origin: USA
Function: Routes video from multiple racks and provides the user display interface

Power Specifications
Supply Voltage: +24 V DC via rack interface
Power Consumption: Determined by display backlighting and router electronics
Protection: Internal regulation, tolerance to supply variances

Communication & Interface
Video Routing: Router accepts VGA inputs from up to four racks
Display Output: VGA module drives touch‑screen or standard display
Control Signals: Router logic steers which rack is shown; display module shows alarms, events, system data
Diagnostics: LEDs for OK, TX/RX, active selection

Environmental
Operating Temperature: –30 °C to +65 °C
Storage Temperature: –40 °C to +85 °C
Humidity: 5% to 95% RH, non‑condensing
Installation: Fits into 3500/94 display cabinet or remote display mounting

Dimensions & Weight
Dimensions: 241.3 × 24.4 × 241.8 mm
Weight: 0.73 kg

Genuine new stock available, customer service online all day for pricing and inquiries.
