Overview
The Honeywell FS‑TSAI‑0410 is a fault‑tolerant analog input module designed for use in safety instrumented systems. It supports four analog channels and integrates field termination and diagnostics for safe analog signal acquisition.
General Information
Brand: Honeywell
Country of Origin: United States
Model Number: FS‑TSAI‑0410
Product Type: Safe Analog Input Module
Application: Safety systems and process control requiring reliable analog signal input
Power Specifications
Supply Voltage: 24 V DC nominal
Channels: 4 analog input channels
Protection Features: Signal isolation, short‑circuit detection, health‑monitoring diagnostics
Communication & Interface
Input Types: Voltage or current analog signals (selectable)
Interface: Field termination assembly module (FTA) connecting system bus to field wiring
Diagnostics: Channel fault detection, status indication, diagnostic reporting
Environmental
Operating Temperature: –40 °C to +70 °C
Storage Temperature: –55 °C to +85 °C
Humidity: Up to 95% RH, non‑condensing
Mounting: Panel or cabinet mount in industrial control environments
Dimensions & Weight
Dimensions (L × W × H): 190 × 185 × 65 mm (approximate)
Weight: Approx. 0.43 kg
