Honeywell MU-PAIL02 (51304481-100) | Low-Level Analog Input

Overview

The MU-PAIL02 module (part number 51304481-100) is a low-level analog input processor used in Honeywell UCN/Experion control systems. It handles low-level sensor inputs such as thermocouples and RTDs, providing precision signal conditioning and isolated processing for the control system.

General Information

Part Number: 51304481-100
Manufacturer: Honeywell
Brand / Country of Origin: Honeywell / USA
Series: MU-PAIL02 (LLAI IOP)
Type: Low-Level Analog Input Processor
Function: Converts low-level analog inputs (RTD, thermocouple) into digital data for the control system.

Power Specifications

Supply Voltage: Provided via system backplane
Input Channels: Supports 8 channels of low-level analog inputs (RTD or thermocouples)
Protection: Channel isolation and input protection for safe operation
Application Range: Thermocouple types B, E, J, K, R, S, T; RTD types Pt100 (DIN/JIS), Ni120 (Edison type 7), Cu10 standard

Communication & Interface

Interface Type: Rack backplane compatible with Honeywell control systems
Input Channel Configuration: 8 analog input channels designed for low‐level sensor signals
Diagnostics: Channel fault detection, module health monitoring
Compatibility: Compatible with Honeywell UCN/Experion I/O architecture and associated field termination assemblies

Environmental

Operating Temperature: Industrial range (typical)
Humidity: Up to 95% RH, non‐condensing
Protection Rating: Suitable for cabinet installation (IP20 rating when installed in enclosure)
Cooling: Passive (natural convection)

Dimensions & Weight

Dimensions (L × W × H): 130 x 35 x 110 mm
Weight: Approximate 0.45 kg

Get genuine brand-new products today, available in stock with fast and accurate pricing.
