Triconex 9863‑710 | Analog Output Interface Quality Selection

Overview
The Triconex 9863‑710 functions as a termination or interface panel module for use with Triconex controller systems. It supports analog output modules in the system, providing the necessary wiring interface, monitoring, and reliable signal routing for critical analog outputs within fault‑tolerant control architectures.

General Information
Brand: Triconex
Country of Origin: United States
Model Number: 9863‑710
Series: Tricon Analog Output Panels / Interface Modules
Product Type: Termination/Interface Panel for Analog Output Modules
Application: Fault‑tolerant process control systems, safety instrumented systems (SIS), analog output terminations

Power Specifications
Supply Voltage: Module receives backplane power typical of Tricon chassis
Power Consumption: Approximate and dependent on connected analog output module (termination panel role)
Protection Features: Provides wiring isolation, loop monitoring, and output wiring fault detection as required by system architecture

Communication & Interface
Function: Interfaces between analog output modules (such as 3806E) and field wiring; provides loop terminals, monitoring connections, and ensures correct routing of analog output signals
Signal Type: Analog current loops (for example 4‑20 mA) depending on connected module
Diagnostics: Supports wiring fault monitoring, integrity checks, and is compatible with Tricon control logic diagnostics

Environmental
Operating Temperature: –40 °C to +70 °C
Storage Temperature: –55 °C to +85 °C
Humidity: Up to 95% RH, non‑condensing
Installation: Rack or cabinet mounted in industrial control environment, designed for redundant/fault‑tolerant systems

Dimensions & Weight
Dimensions (L × W × H): Approx. 127 × 203 × 114 mm
Weight: Approx. 1.2 kg

Authentic factory-sealed products, ready for immediate shipment.
