Overview
The Yokogawa AAV544‑S00 is a 16‑channel isolated analog output module designed to generate precise voltage outputs in industrial control systems.
General Information
Part Number: AAV544‑S00
Brand / Country of Origin: Yokogawa / Japan
Product Type: Analog Output Module
Series: AAV544
Power Specifications
Supply Voltage: Powered via the system I/O rack backplane
Output Signal Range: –10 V to +10 V per channel
Accuracy: ±0.3 % of full scale or ±12 mV, whichever is greater
Channel Count: 16 isolated output channels
Communication & Interface
Interface Type: Rack‑mounted module with backplane connection
Signal Connections: Voltage output terminals compatible with –10 V to +10 V loads
Diagnostics: Channel fault detection and status monitoring supported
Compatibility: Works with Yokogawa distributed control system I/O racks
Environmental
Operating Temperature: −20 °C to +70 °C
Storage Temperature: −40 °C to +85 °C
Humidity: Up to 95% RH, non‑condensing
Protection Rating: IP20 when installed in an enclosure
Dimensions & Weight
Dimensions (L × W × H): 107.5 × 130 × 32.8 mm
Weight: Approx. 0.20 kg
