Overview
The ABB 3BUS208802-001 is a standard signal jumper board used in ABB Advant and Master control systems. It enables reliable signal routing between I/O slices, ensuring smooth communication and accurate signal transmission in industrial automation environments.
General Information
Part Number: 3BUS208802-001
Manufacturer: ABB
Brand / Country of Origin: ABB / Sweden
Series: I/O Accessories
Type: Signal Jumper Board
Mounting: Rack-mounted or installed within control cabinet
Function: Routes and connects standard I/O signals between modules
Power Specifications
Supply Voltage: 24 V DC nominal
Power Consumption: ≤ 5 W
Protection: Overvoltage and short-circuit protection
Indicators: LEDs for signal and power status
Communication & Interface
System Connection: Connects I/O slices through backplane interface
Interface Type: Digital signal jumper routing
Diagnostics: LED indicators for signal continuity and fault monitoring
Compatibility: Compatible with ABB Advant / Master I/O systems
Reset Features: Supports system-level resets
Environmental
Operating Temperature: −25 to +70 °C
Storage Temperature: −40 to +85 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20
Cooling: Natural convection
Dimensions & Weight
Dimensions (L × W × H): 247 × 56 × 145 mm
Weight: Approx. 0.38 kg
