Overview
The ABB 3BUS212310-002 is a dilution drive module developed for precise control in ABB automation and process systems. It manages drive operations for dilution processes, ensuring stable performance, accurate control, and efficient operation in industrial environments such as paper, chemical, and process industries.
General Information
Part Number: 3BUS212310-002
Manufacturer: ABB
Brand / Country of Origin: ABB / Sweden
Series: Drive Control Series
Type: Dilution Drive Module
Mounting: Rack or panel installation within control cabinet
Function: Provides regulated drive control for dilution and process control applications
Power Specifications
Supply Voltage: 24 V DC nominal
Power Output: Control-level drive power for dilution actuators
Current Rating: Up to 5 A
Power Consumption: ≤ 60 W typical
Protection: Overvoltage, short-circuit, and thermal protection
Indicators: LEDs for power, communication, and fault status
Communication & Interface
System Bus Connection: Integrated interface for communication with ABB control network
Control Interface: Supports analog and digital signal exchange for drive control
Diagnostics: LED indicators for operational and fault monitoring
Compatibility: Designed for ABB industrial control and motion systems
Reset Features: Software and hardware reset supported
Environmental
Operating Temperature: −25 to +70 °C
Storage Temperature: −40 to +85 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20 (for use in protected enclosures)
Cooling: Natural convection
Dimensions & Weight
Dimensions (L × W × H): 200 × 60 × 120 mm
Weight: Approx. 1.86 kg
