Overview
The ABB FI 810F 3BDH000030R1 is a flow interface module designed for ABB automation systems. It accurately monitors and transmits flow-related signals from field devices, ensuring precise data acquisition and reliable process control in industrial environments.
General Information
Part Number: 3BDH000030R1
Manufacturer: ABB
Brand / Country of Origin: ABB / Sweden
Series: FI (Flow Interface)
Type: Flow Interface Module
Mounting: Rack or panel installation
Function: Measures and communicates flow signals to the control system for monitoring and control
Power Specifications
Supply Voltage: 24 V DC nominal
Power Consumption: ≤ 5 W
Protection: Overvoltage and short-circuit protection
Indicators: LEDs for power, communication, and fault status
Communication & Interface
Interface Type: Digital and analog signal interface
System Connection: Connects to ABB Advant / Master automation backplane
Diagnostics: LED indicators for operational status and fault detection
Compatibility: Compatible with ABB flow measurement and control modules
Reset Features: Supports hardware and software reset
Environmental
Operating Temperature: −25 to +70 °C
Storage Temperature: −40 to +85 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20
Cooling: Natural convection
Dimensions & Weight
Dimensions (L × W × H): 125 × 155 × 28 mm
Weight: Approx. 0.145 kg
