Overview
The ABB EI813F 3BDH000022R1 is an energy interface module designed for ABB automation and control systems. It provides precise monitoring and transmission of energy signals from field devices, supporting accurate data acquisition and reliable system operation in industrial environments.
General Information
Part Number: 3BDH000022R1
Manufacturer: ABB
Brand / Country of Origin: ABB / Sweden
Series: EI (Energy Interface)
Type: Energy Interface Module
Mounting: Rack or panel installation
Function: Measures, monitors, and transmits energy-related signals to the control system
Power Specifications
Supply Voltage: 24 V DC nominal
Power Consumption: ≤ 5 W
Protection: Overvoltage and short-circuit protection
Indicators: LEDs for power, communication, and fault status
Communication & Interface
Interface Type: Digital and analog signal interface
System Connection: Connects to ABB Advant / Master automation backplane
Diagnostics: LED indicators for operational status and fault detection
Compatibility: Compatible with ABB energy monitoring and control modules
Reset Features: Supports hardware and software reset
Environmental
Operating Temperature: −25 to +70 °C
Storage Temperature: −40 to +85 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20
Cooling: Natural convection
Dimensions & Weight
Dimensions (L × W × H): 125 × 155 × 28 mm
Weight: 0.15 kg
