Overview
The GE IS200DRLYH1BBB is a relay output module built for industrial automation and control systems. It provides multiple relay channels to drive actuators, solenoids and other discrete outputs with strong electrical isolation and reliable performance.
General Information
Part Number: IS200DRLYH1BBB
Brand / Country of Origin: GE / USA
Product Type: Relay Output Module
Application: Industrial automation and process control systems
Power Specifications
Number of Outputs: 16 relay channels
Output Voltage: Configurable for 24 V DC or 120 V AC
Output Load: Up to 2 A per channel
Isolation: Channel-to-channel and channel-to-system isolation supported
Communication & Interface
Interface Type: Backplane rack connection for module insertion
Output Signals: Multiple relay contacts driving discrete loads
Diagnostics: Status LEDs and fault indicators for monitoring channel health
Compatibility: Fits GE Mark VI/Mark VIe I/O library
Environmental
Operating Temperature: -20 °C to +70 °C
Storage Temperature: -40 °C to +85 °C
Humidity: Up to 95% RH, non‑condensing
Protection Rating: IP20 when installed in cabinet
Dimensions & Weight
Dimensions (L × W × H): Approximately 180 × 120 × 60 mm
Weight: Approx. 0.30 kg
