Honeywell 8C-PAIMA1 51454473-175 Analog Input Module Recommended products

Overview

The Honeywell 8C-PAIMA1 51454473-175 is a 16-channel low-level analog input module designed for use in Honeywell's Series 8 C300 control systems. It interfaces with thermocouple (TC) and Resistance Temperature Detector (RTD) sensors to provide accurate temperature measurements in industrial applications.

General Information

• Part Number: 8C-PAIMA1 51454473-175

• Manufacturer: Honeywell

• Series: Series 8 C300

• Module Type: Analog Input Module (AI)

• Input Channels: 16 isolated channels

• Mounting: Rack-mounted in Series 8 I/O chassis

Input Specifications

• Input Types:

• Thermocouple (TC): Types J, K, T, E, R, S, B

• RTD: 2-wire, 3-wire, and 4-wire configurations

• Input Range:

• TC: -200°C to +850°C

• RTD: -200°C to +400°C

• Accuracy: ±0.15% of full scale

• Resolution: 16-bit A/D conversion

• Signal Conditioning: Cold-junction compensation, linearization, filtering

Power and Environmental

• Supply Voltage: 24 V DC

• Power Consumption: Approximately 6.5 W

• Operating Temperature: -40°C to +70°C

• Storage Temperature: -40°C to +85°C

• Humidity: 5% to 95% RH, non-condensing

• Protection Rating: IP20 (for installation inside an industrial cabinet)

Communication and Diagnostics

• Communication Protocol: HART (Highway Addressable Remote Transducer)

• Diagnostics: LED indicators for power, communication, and channel status

• Isolation: 500 V galvanic isolation between channels and ground

Dimensions and Weight

• Dimensions (L × W × H): 220  × 120  × 60 mm

• Weight: Approximately 0.6 kg

Brand-new original inventory, ready to ship, 24-hour professional support available.
