Overview
The Honeywell MC-PDOY22 is a high-density digital output module designed for industrial automation and control systems. It supports 32 independent output channels and is optimized for reliable actuation of field devices such as valves, relays, and motors.
General Information
Brand: Honeywell
Country of Origin: United States
Model Number: MC-PDOY22 / 80363975-150
Product Type: Digital Output Module
Application: Process automation and control systems requiring extensive output channel capacity
Power Specifications
Supply Voltage: 15–30 V DC (standard module variant)
Maximum Load: Up to 250 VAC or 125 V DC (via auxiliary output cards)
Protection: Overload, short-circuit, and reverse-polarity protection
Communication & Interface
Output Channels: 32 independent digital output channels
Signal Type: Open-collector or Form C dry contact outputs depending on variant
Diagnostics: Channel status monitoring and fault detection supported via system interface
Environmental
Operating Temperature: –40 °C to +85 °C
Humidity: Up to 95% RH, non-condensing
Installation: Rack or panel mounted in industrial control cabinet
Dimensions & Weight
Dimensions (L × W × H): Approx. 321 × 107 × 130 mm
Weight: Approx. 0.60 kg
