Overview
The Honeywell MU‑TAIH22 is a high-level analog input module designed for industrial control systems. It accepts multiple analog signals and converts them into digital data for real‑time monitoring and control.
General Information
Part Number: 80366195‑100
Manufacturer: Honeywell
Brand / Country of Origin: Honeywell / USA
Type: High-Level Analog Input Module
Function: Processes high-level analog input signals for use in DCS architectures
Power Specifications
Supply Voltage: Via system backplane
Input Signal Range: Configurable for high-level analog inputs
Resolution & Accuracy: Built for precision analog input conversion and robust performance against noise
Communication & Interface
Interface Type: Rack backplane connection compatible with Honeywell I/O processors
Input Channels: Supports multiple high-level analog inputs
Diagnostics: Includes fault detection and diagnostics for channel health and signal integrity
Environmental
Operating Temperature: −40 °C to +70 °C
Storage Temperature: −40 °C to +85 °C
Humidity: Up to 95% RH, non‑condensing
Protection Rating: IP20 when installed in an enclosure
Cooling: Passive (natural convection)
Dimensions & Weight
Dimensions (L × W × H): 127 × 110 × 25 mm
Weight: Approx. 1.75 kg
