Overview
The ABB EI 803F 3BDH000017R1 is an energy interface module designed for ABB automation and control systems. It monitors and manages energy signals from field devices, ensuring accurate data acquisition and stable operation in industrial environments. The module supports efficient energy management and system diagnostics.
General Information
Part Number: 3BDH000017R1
Manufacturer: ABB
Brand / Country of Origin: ABB / Sweden
Series: EI (Energy Interface)
Type: Energy Interface Module
Mounting: Rack or panel installation
Function: Measures, monitors, and transmits energy-related signals to the control system
Power Specifications
Supply Voltage: 24 V DC nominal
Power Consumption: ≤ 10 W
Protection: Overvoltage and short-circuit protection
Indicators: LEDs for power, communication, and fault status
Communication & Interface
Interface Type: Digital and analog signal interface for energy monitoring
System Connection: Connects to ABB Advant / Master I/O backplane
Diagnostics: LED indicators for operational and fault status
Compatibility: Compatible with ABB energy monitoring and automation modules
Reset Features: Supports hardware and software reset
Environmental
Operating Temperature: −25 to +70 °C
Storage Temperature: −40 to +85 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20
Cooling: Natural convection
Dimensions & Weight
Dimensions (L × W × H): 200 × 50 × 120 mm (approximate)
Weight: Approx. 0.5 kg
