Woodward 5417-027 Cable New In Stock

Overview

The Woodward 5417‑027 is a microprocessor-based speed controller and synchronizer designed for three-phase AC generator systems. It offers low-current PWM output and supports both analog and discrete inputs for frequency, phase, and voltage matching applications, ideal for diesel, gas, and steam turbine-driven generators.

General Information

• Part Number: 5417‑027

• Manufacturer: Woodward

• Type: Digital Speed Controller / Synchronizer

• Mounting: Panel or chassis mount

• Technology: Microprocessor-controlled module with dual serial interface and PWM outputs

Power Specifications

• Supply Voltage: 18–36 V DC (nominal 24 V DC)

• Power Consumption: Low-power design

• Protection:
  • Surge and reverse voltage protection
  • Galvanic isolation on outputs

• Indicators: LED status for power, mode, fault, and communication

Communication & Interface

• Serial Ports:
  • RS-232 and RS-422 (independent) for setup, diagnostics, or integration

• PWM Output: Low-current output for driving generator field or control inputs

• Functionality:
  • Automatic phase, frequency, and voltage matching using analog or discrete reference input
  • Optional Modbus serial communication
  • Dual redundant Ethernet support available

• Diagnostics: Real-time monitoring with fault detection and logging

I/O & Channels

• PWM Outputs: 1 external control output

• Analog Inputs: Supports both voltage and discrete inputs for control signals

• Control Features:
  • Speed/load control loops
  • Governors, soft start/load transfer, torque or manifold pressure limiting, auto idle control
  • Configurable for diesel, gas, or steam turbines

• Synchronization: Provides automatic synchronizing signals to match frequency, phase, and voltage prior to connecting generators

Environmental

• Operating Temperature: –40 °C to +100 °C

• Vibration & Shock: Designed for high-vibration industrial environments

• Humidity: Industrial rated; environmental protection per standards

• Certifications: Suitable for Class I Division environments; industrial-grade reliability

Dimensions & Weight

• Size: Compact module size (panel/chassis mountable)

• Weight: Approximately 0.6 kg

Applications

Ideal for generator sets powered by turbines or industrial engines, providing critical control and synchronizing functions in:

• Diesel and gas engine generator sets

• Steam, gas, and hydraulic turbine controls

• Load sharing, soft-load transfer, and auto-synchronization systems
